When we launched the Trail Edition back in 2017 it was a game changer for bike lights.
A beam pattern specifically designed for trail riding with a wide evenly illuminated distribution. However it required an external battery pack, and we had lots of customers wanting to go wireless.
So we took the best parts of Trail, and evolved it into the Trail Evo. Bringing a long lasting, even brighter, even wider beam pattern to your handlebars, without any external cords.
When we developed Evo’s beam pattern, we knew we could go wider and brighter, so we redefined our illumination goals, target candela points, beam angles, and then went to work simulating, testing, prototyping and developing the most seamless pattern we've built to date.
The extreme width is thanks to the finely tuned blended Total Internal Reflection (TIR) optics. Hundreds of simulations with Lucidshape software let us squish, squeeze, stretch and shape the light to hit that perfect balance of peak brightness, smooth falloff and insane peripheral coverage.
Check the slider comparison below to see the difference between a fine tuned optical instrument such as Trail Evo vs a name-brand light that has been around for years. The difference is staggering in person.
Rock Solid Mounting
A good light isn’t so good if
it’s bouncing up and down on all the time. That’s why we made a bolt-on clamp mount for Evo. It’s solidly locked to the bar and the beam won’t shake around like lights with rubber strap mounts do.
It's an easy one-handed quick-release process to pop Trail Evo off post-ride to charge.
|Lumens||~ 2200 lumens|
|Battery||10,000mAH capacity / 2x LG 21700 M50LT cells|
|Weight||275g Trail Evo Lighthead|
|36g Quick Release Mount|
|Modes||Adaptive - High - Medium - Low|
|Daytime Flash/Nighttime Flash|
|Materials||Magnesium lower shell|
|Glass Fiber Reinforced Nylon Mount|
|High Strength polycarbonate substrate|
|Soft touch TPU overmold|
|High clarity PMMA lens|
|Electrical Features||Thermal protection circuit|
|Constant current step-down converter|
|Battery management system|
|QC3.0 USB-C charging|
|Low Battery warning|
|20 minute "get-home" buffer in every mode|
|What's in the box||Trail Evo Lighthead|
|Quick Release Bar Mount for 35mm bars|
|31.8mm shim (25.4mm and 22.2mm available)|
|M2.5 Allen Key|
|USB-C to USB-A charging cable (USB-C to USB-C available)|
|Instruction Manual (Download HERE)|
|Adaptive||2.6 h (155 min)|
|High||1.7 hr (104 min)|
|Medium||4.2 hr (250 min)|
|Low||8.5 hr (500 min)|
|Daytime Strobe||10 hr (600 min)|
|Nighttime Flash||4.5 hr (270 min)|
